Why is Power Sequencing Required for FPGAs, ASICs, CPUs, etc?

To avoid contention on signals as the board is powered on and off
To prevent excessive current draw
To prevent latch-up, reduced reliability or damage to devices
To address power down sequencing requirements during sudden loss of power, or brownout

Here you can download the new programmable module residing in the MAX FPGA, providing the ability to monitor and correctly sequence power rails for FPGAs, ASICs, and other processors provided as open source design.

Features

Sequence and monitor any combination of up to 144 rails
- Up to 18 voltage-monitored rails per Intel^® MAX^® 10 device
- Up to 144 digital-monitored (POK) rails per Intel^® MAX^® 10 device
Monitor overvoltage, undervoltage, and power good status
PMBusTM 1.2 compliant slave interface
Set defaults and dynamically control levels for overvoltage, undervoltage, and power good with programmable response behavior
Easily configurable via Platform Designer GUI
Includes simulation testbench
